N1MM Logger - Free Contest Logging Software

• Win 95/98/ME & NT/2000/XP (no DOS) support.
• Contests supported:
  • ALL Asian
  • ARRL DX
  • ARRL FD
  • ARRL Sweepstakes
  • ARRL 10M
  • BARTG Sprint
  • Generic QSO Party
  • CQ WW
  • CQ WPX
  • IARU
  • NAQSO
  • PACC
  • RTTY Roundup
  • TARA PSK
  • General DX log/DXpedition support.
• Uses sound card for dvk.
• Contact recording to wav files. Right-click on log entry to play back.
• Automatic cw generation.
• RTTY & PSK31 support.
• The program retains the size and position of windows as specified by the user. The windows below are shown tiled, but they may overlap as desired.
• The main windows (Main, Log, Bandmaps, Packet, Check, and Available Mults and Q's) are non-modal. That is, you can interact with any of them without having to close the last window used.
• Available Window keeps track of needed spots & mults on each band for easy band-change decisions. Color-coded buttons indicate on which bands the current contact is needed.
• Radio interface to Kenwood, FT-1000, FT-1000MP, FT-990, FT-920 Icom, Elecraft.
• Click on packet spot in packet window to tune to that frequency/mode.
• Spotted stations appear on callsign textbox frame when you tune near a spot. A touch of the space bar will enter that call into the callsign field.
• Mode-aware fine tuning from the keyboard.
• Automatic beam heading and sunrise/sunset calculations.
• Check partial function.
• Packet & Telnet support - spots from both automatically update the band maps.
• CW sending from the keyboard.
• Dual graphical bandmaps click to tune radio to the spot selected. The bandmap can be zoomed in or out depending on number of spots showing.
• Two radio support. Two VFO support when using one radio. One VFO/Bandmap. The image below is of a one-radio configuration.
• Multiplier window.
• LPT port functionality to control antenna switches, radio selected, and ptt (95/98/ME/NT/2000/XP)
• Cabrillo import/export support.
• Multi-user support (in development).
• ADIF import/export support.
• All data is stored in an Access 2000 database to facilitate reporting and future integration with other software.

• Coded in Visual Basic 6.0 using no aftermarket controls.
• Current exe size (p-code) about 1200k.
• 20 Forms, 10 modules, 34 classes.
• 20,000+ lines of code.
• Uses one freeware dll for lpt port control.
• Database is Access 2000.
• Uses data-bound controls for log and check functions.
• The logging program has been designed to work on a Pentium II 233 MHz as a minimum platform. Thus, it runs reasonably on a 233 Pentium II. It has not been and won't be a priority to make it run on clunkers.

Are you interested in working on this?
